Cal Flame BBQ08874CP - Page 36

Convection Grills
LTR50001038, Rev. J
Appendix
www.calamebbq.com
34
You will need:
• 6mm socket or nut driver
• Four or ve 1.9mm orices (depending on
your grill
• Pipe compound suitable for natural gas
Step 2: Change the main burner
orices
b. Remove the locking pins from the end of the
burners.
The locking pins are accessible by removing
the drip tray and tilting the grill back. They can
be seen underneath the grill in the back. See
gures below.
c. Remove all burners by carefully lifting them up
and away from the valve orice.
d. Using a 6mm socket or nut driver, remove the
orice for the burner.
e. Apply a small amount of pipe compound to the
orice threads.
f. Screw in the orice until it is nger tight.
g. Tighten the orice with the 6mm wrench.
h. Repeat the above steps for the remaining
burners.
i. Replace the burners, ame tamers, drip tray,
and grates.
You do not need to replace the locking pins. They
are used to keep the burners in place during
shipping and are not necessary to operate your
grill.
Gas Conversion (continued)
W
ID
T
H
W
ID
T
H
W
ID
T
H
W
ID
T
H
Minimum
Clearance
12” Minimum Distance
Between Grill and Side Burner
Minimum
Clearance
Screen Vents
W
ID
T
H
W
ID
T
H
WIDTH
DEPTH
WIDTH
WIDTH
DEPTH
WIDTH
WIDTH
WIDTH
DEPTH
DEPTH
DEPTH
HEIGHT
HEIGHT
HEIGHT
Burner
Locking Pin
Burner
Locking Pin
Orice
a. Remove the grates, ame tamers, and drip tray
from the grill. See gure below.
