CalAmp Guardian-100 User Manual

001-5006-000_FCC.docx Page 50
Figure 2-24 End to End Test: Text message sent
The ASCII message is transmitted to the other GUARDIAN. The ASCII terminal program will display
the
received ASCII message in the Rx Data area as shown Figure 2-25.
Type in this area to send the text message
2-37
001-4006-101
Figure 2-25 Text message received
If the message was not displayed as typed, then a problem may exist in the system. Check all parameters
and connections in the system. The signal level should also be checked again. The GUARDIAN‟s Link
Test
utility can be used to verify a communication path.
