TECHNICAL DATA SHEET FOR
MODEL BEF- 5 BEAM END FITTINGS
Precautions:
1. Never attempt to lift loads beyond the specified maximum capacity.
2. Verify the top rigging is at a minimum angle of 45 degrees. If this angle is lower than 45
degrees the spreader system is at risk of being overloaded.
Inspection & Maintenance:
1. Inspect all welds or cracks.
2. Inspect all rigging and hardware for wear and fit.
Additional requirements to fully conform to ASME B30.20:
1. Rated Load Marking (ASME B30.20 Section 20-1.2(a))
The rated load of the lifting device shall be marked on the main structure where it is
visible. If the lifting device is made up of several lifters, each detachable from the group,
these lifters shall also be marked with their individual rated loads.
2. Identification (ASME B30.20 Section 20-1.2 (b))
A nameplate or other permanent marking shall be affixed displaying the following
information:
1. Manufacturer's name and address
2. Serial Number
3. Lifter Weight, if over 100 lbs (45 kg)
4. Rated Load
NOTE: IF TAGS OR DECALS BECOME DIFFICULT TO READ, CONTACT THE
CALDWELL GROUP FOR REPLACEMENT TAGS AND DECALS.
ASME BTH-1
DESIGN CATEGORY: B
SERVICE CLASS: 0
BEF-5 (REV_03_102220)
