Materials: - body: brass, EN 12165 CW617N
- obturator stem: stainless steel
- obturator: EPDM
Medium: water, glycol solutions
Max. percentage of glycol: 30 %
Working temperature range: 0–90 °C
Medium peak temperature: 110 °C
Max. working pressure: 16 bar
Connections: Ø 22 for copper pipes
Transformer: 1-phase with separated windings, protected against short circuit (PTC)
Plug: Euro plug, suitable for power outlets with and without ground
Voltage: Primary: 230 V, 50 Hz 100 mA
Secondary: 24 V, 50 Hz 150 mA
Power: 10,8 VA
Connection cable: 2-wire, length about 1 m
Max. permissible temperature: - housing: 40 °C
- cable: 130 °C
Protection class: IP 20 classe 2
Valve technical
specification
Materials: - base and cover: PC G10
Synchronous motor - Normally closed
Electric supply: 24 V - 50 Hz
Power consumption: 6,5 W; 7 VA
Opening time: 70–75 s
Closing time: 5–7 s
Auxiliary microswitch contact rating: 0,8 A
Auxiliary reed switch: 0,3 A / Vmax 24 V
Protection class: IP 20
Conforms to Normes/Directives: EN 60730-1 • EN 60730-2-14
2014/30/EU • 2014/35/EU
Supply cable: 5x0,75 mm
2
- lenght 95 cm
Actuator
technical
specifications
Power plug
Medium working temperature range: 0–90 °C
Ambient temperatures: - Operation: 0–40 °C EN 60721-3-3 Class 3K3
max umidity 85 %
- Transport: -20–70 °C EN 60721-3-2 Class 2K2
max umidity 95 %
- Storage: -5–50 °C EN 60721-3-1 Class 1K2
max umidity 95 %
Ambient
conditions
3
Hydraulic
characteristics
Connection
Ø 22
Size
DN 20
Kv (m
3
/h)
4,5
Max. differential pressure (kPa)
150
