CALEFFI 7200 Series - Page 11

11
TABLE 1 - Mounting kit MONITOR 2.0
2. INSTALLATION AND MAPPING (to be carried out by the installer)
DD
DD
Element radiators
MOUNTING
KIT
Cast iron columns
Distance
between elements (D)
less than or equal to
30 mm
Distance
between elements (D)
greater than 30 mm
Steel tubular
Tubolare acciaio
a colonne
Passo
degli elementi
da 45/46 mm
Aluminium columns
Ribbed steel
720050*
720052*
720060*
720061*
720060*
720061*
D
Distance between
elements (D)
less than or equal to 35 mm
Distance between
elements (D)
from 36 to 45 mm
720051*
720053*
* Minimum 5-piece pack
44
Distance between
elements (D)
less than or equal to
4 mm
Distance between
elements (D)
from 4 to 10 mm
720052*
720054*
Distance between
element centres (C)
less than 50 mm
and distance (D)
less than 30 mm
Distance between
element centres (C)
greater than or equal to
50 mm and
distance (D)
less than 30 mm
D
D 30
Cast iron plates
Distance
between elements (D)
less than or equal to
4 mm
Distance
between elements (D)
from 4 to 10 mm
35
35 D 45
D
