CALEFFI 7200 Series - Page 12

12
Passo
* Minimum 5-piece pack
Panel radiators
Ridged surface
Vertical profile
Smooth surface
Vertical
Horizontal
Flat tubes
720062*
Smooth surface
Lamellar radiators
Lamellar
Lamellar
720063
Towel warmer
Horizontal tubes
720050*
Distance between
elements (D)
from 24 to 28 mm
D
24 D 28
Towel radiator
MOUNTING
KIT
MOUNTING
KIT
MOUNTING
KIT
TABLE 1 - Mounting kit MONITOR 2.0
2. INSTALLATION AND MAPPING (to be carried out by the installer)
