Overview
•Compatiblewith2,3and4-wirethermostatsorother
low voltage controllers with switching action
•120VACinput
•Heavyduty,sealed,DPDT,fuseprotectedrelay 
(with spare fuse)
•Twodrycontactoutputs(Relay1andRelay2)for
operating 120 VAC pump with boiler enable or two
devices without boiler enable
•5Acapacityeachrelay-10Atotal
•Rearknock-outsformountingonto4”x4”junctionbox
•Highcapacity6VAtransformer
•Simpliedwiringwithpre-installedjumper
•100%factorytestedwith3yearwarranty
•ETLcertied
See technical brochure 01284 NA for more product
information.
4009064
Certified to CSA C22-2 No.24
Conforms to UL Standard 873
ZSR101 - Single Zone Switching Relay
