Parameters
You can provision the following parameters for an MVR profile and address ranges:
Parameter Description Valid Options
Name*
Name of the MVR profile.
32 character string
MVR VLAN ID* Index value designating the VLAN to be assigned address
ranges.
any existing video VLAN
Address Range#
Start*
First address in the MVR VLAN range. Multicast IP address in "dotted quad"
format: "224.0.0.1".
Address Range#
End*
Last address in the MVR VLAN range.
The full range of Multicast addresses:
 Start 224.0.0.1

Stop is 239.255.255.255
Multicast IP address in "dotted quad"
format: "224.0.0.1".
*Required fields
To create an MVR profile and MVR VLAN addresses
1. Access the profile page:
 From CMS:
 On the Navigation Tree, click CMS.
 In the Work Area, click Profile > E3-48C/E5-48/E7/ONT > Profile >
Service > Multicast > MVR.
 Locally on the node:
 On the Navigation Tree, click the unit.
 In the Work Area, click Profiles > Service > Multicast > MVR > Profiles.
2. In the menu, click Create to open the Create MVR Profile dialog box.
3. In the Name box, enter a descriptive name for the profile, and then click Create.
4. In the list of existing MVR profiles, double-click the profile name to select it.
5. In the menu, click Create to open the Create MVR VLAN dialog box.
6. Reference the table above to configure the parameters.
7. Click Create to add the MVR VLAN to the MVR profile.
8. Associate the MVR profile when creating a multicast profile.
For CLI:
 create mvr-profile <p-name>
 add vlan <vlan-id> to-mvr-profile <p-name> [mcast-range-1|mcast-range-
2|mcast-range-3|mcast-range-4]
 delete mvr-profile <p-name>
