113
.............................................................................................................................................................................................................................................
S2
DL3678 COMPRESSOR/LIMITER DIL SWITCHES
SW4 "M" detection:-
DOWN = OFF.
UP = ON = Detection of reduced mono signal into side chain (see note).
N.B. The compressor and limiter normally respond to the higher of the left and right signals. SW2
allows the mono reduction of left and right (-3dB) to take control it the stereo coherence is such that
this exceeds left or right. This renders it unnecessary to "under-drive" the stereo outputs to guard
against the possibility of a higher than desired mono level.
