Calrec S2 - Modules List

12
............................................................................................................................................................................................................................................
S2
MODULES LIST
2.1 PQ4068 Mono channel page 14
2.2 PQ4069 Stereo channel 16
2.3 BQ4070 Stereo Line channel 18
2.4 XL4071 Group 20
2.5 LC4341 Main output 22
2.6 IC4061 Channel/Group fader 24
2.7 IM4064 Main output fader 25
2.8 IG4062 VCA Group Twin fader 26
2.9 IV4063 VCA Master fader 27
2.10 TY3660 Tone/Talkback 28
2.11 ML4230 Monitor LS 29
2.12 ML4231 Loudspeaker 2 (option) 30
2.13 WI6964 Surround Monitor 31
2.14 MY3681-2 Multi-track bargraph/control (option) 32
2.15 AY3938 Multitrack Ancilliary Functions control 33
2.16 MY3680 Meter selector (General) 34
2.17 MY3875 Meter selector (Principal Selections) 34
2.18 MY3876 Meter selector (Main Function) 34
