STEP 6
Drawer Glide Adjustments:
The metal drawer glides are designed to allow for slight adjustments vertically and
horizontally, if necessary.
Horizontal Glide Adjustment:
Vertical Glide Adjustment:
Remove drawer from chest. Loosen screws indicated on side of metal track. Make needed
space adjustment and re-tighten screws and add 2 additional screws in holes as indicted in
diagram below:
Remove drawer from chest. Loosen Screws on underside of metal track. Make needed space
adjustment and re-tighten screws as indicated in diagram below:
- 3,5x14 Screw
Qty.
D
20
