SAFETY PRECAUTIONS
CHECKING THE POWER SUPPLY SETTING
For your own safety please read the following instructions carefully before
attempting to connect this unit to the mains.
• Check that the rear of your unit indicates the correct supply voltage.
• If your mains supply voltage is different, consult your dealer.
This unit is designed to operate only on the supply voltage and type that is
indicated on the rear panel of the unit. Connecting to other power sources
may damage the unit.
SAFETY PRECAUTIONS
This equipment must be switched off when not in use and must not be used
unless correctly earthed. To reduce the risk of electric shock, do not remove
the unit’s cover (or back). There are no user serviceable parts inside. Refer
servicing to qualified service personnel. If the power cord is fitted with a
moulded mains plug the unit must not be used if the plastic fuse carrier is not
in place. Should you lose the fuse carrier the correct part must be reordered
from your Cambridge Audio dealer.
The lightning flash with the arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
‘dangerous voltage’ within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance instructions in the service literature relevant to
this appliance.
This product complies with European Low Voltage
(73/23/EEC) and Electromagnetic Compatibility
(89/336/EEC) Directives when used according to this
instruction manual. For continued compliance only
Cambridge Audio accessories should be used with this
product and servicing must be referred to qualified
service personnel
PLUG FITTING INSTRUCTIONS (UK ONLY)
The cord supplied with this appliance is factory fitted with a 13A mains plug
fitted with a 3A fuse inside. If it is necessary to change the fuse, it is important
that a 3A one is used. If the plug needs to be changed because it is not
suitable for your socket, or becomes damaged, it should be cut off and an
appropriate plug fitted following the wiring instructions below. The plug must
then be disposed of safely, as insertion into a 13A socket is likely to cause
an electrical hazard. Should it be necessary to fit a 3-pin BS mains plug to
the power cord the wires should be fitted as shown in this diagram. The
colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug. Connect
them as follows:-
• The wire which is coloured BLUE must be
connected to the terminal which is marked
with the letter ‘N’ or coloured BLACK.
• The wire which is coloured BROWN Must be
connected to the terminal which is marked
with the letter ‘L’ or coloured RED
• The wire which is coloured GREEN/
YELLOW must be connected to the terminal
which is marked with the letter ‘E’ or coloured
GREEN.
NOTE: If your model does not have an earth wire, then disregard this
instruction.
If a 13 Amp (BS 1363) plug is used, a 3 Amp fuse must be fitted, or if any
other type of plug is used a 3 Amp or 5 Amp fuse must be fitted, either in the
plug or adaptor, or on the distribution board.
To Next Page
