Cambridge Technology Model 6220H Instruction Manual
2
TABLE OF CONTENTS
1.0 Introduction and Warnings _______________________________________________ 3
2.0 Specification ____________________________________________________________ 5
3.0 Description of Operation__________________________________________________ 7
3.1 Overview _____________________________________________________________ 7
3.2 Mounting Scheme ______________________________________________________ 8
3.3 Mirror Mount and Mirrors _____________________________________________ 10
3.4 Cabling ______________________________________________________________ 11
3.4.1 Attaching the Cable to the Motor ____________________________________ 12
3.4.2 Modifying the Cable Length ________________________________________ 13
3.5 The 6220HM _________________________________________________________ 15
3.5.1 Field Replacement of the Bumpers ___________________________________ 15
4.0 Limited Warranty ______________________________________________________ 16
5.0 Appendix______________________________________________________________ 17
5.1 Schematics and Mechanical Drawings ____________________________________ 17
