CAMBRIONIX ThunderSync3-16 User Guide

6 Specifications
TS3-16
Input Voltage: 100 ~ 250 Vac
Input Current: 3.5A @ 115 VacA
Input Frequency: 47 ~ 63 Hz
Input Connection: C14
Output Voltage: 5.2V
Output Current: 2.4A Max per Port
Output Power: 12W Max per Port
Output Power (Total): 230W Maximum
Input/Output Connectors: 16 x USB3.2 Gen 1
Type-A,
2 x Thunderbolt™ 3
Ambient Operating 10 ~ 35°C
Temperature Range:
Relative humidity: 5% to 95%
non-condensing
Dimensions (approx.): 482 long x 270 wide
x 42 high mm
Approximate weight: 3.7kg
7 Certifications
• Independently safety tested by the Underwriters
Laboratory (UL) under file #E346549
• CE Tested and marked
• CB Certificate
• FCC Part 15 Tested and marked
• RoHS Compliant
• China CCC certification
• Japanese PSE certification (pending)
• Complies with the latest EN62368 safety
requirements for ITE
• Housed within a UL94-V0 specification fire
enclosure
Thunderbolt and the Thunderbolt logo are
trademarks of Intel Corporation in the U.S and/or
other countries.
www.cambrionix.com10

CAMBRIONIX ThunderSync3-16 Specifications
