12
To Remove and Replace Surface Elements and Drip Bowls
To Remove
1. Lift up edge of surface element across from terminal end. Lift just enough to
clear edge of the drip bowl.
2. Gently slide the surface element out of the terminal plug.
3. Lift the drip bowl up and out.
To Replace
1. Line up the opening of the drip bowl with the terminal plug.
2. Hold the surface element as level as possible and slide the terminal end through
the opening and into the terminal plug.
3. Press down on the surface element until the element is horizontal. The surface
element must be level to reduce the hazard of pans sliding off the element.
To Remove and Replace Oven Door
1. Open the door to the fully opened position.
2. Pull up the lock located on the each hinge support and engage it in the hook of
the hinge lever. You may have to apply a little downward pressure on the door
to pull the locks fully over the hooks.
3. Grasp the door by the sides, pull the bottom of the door up and toward you to
disengage the hinge supports.
4. Keep pulling the bottom of the door toward you while rotating the top of the
door toward the range to completely disengage the hinge levers.
5. To reinstall the oven door, reverse steps 1 through 4. Make sure the hinge
supports are fully engaged before unlocking the hinge levers.
General Cleaning
(Continued)
Be careful not to bend
terminal ends when replacing elements
after cleaning.
The door is heavy. For
safe, temporary storage, lay the door
flat with the inside of the door facing
down.
G21D0032
G21D0030
G21D0031
