Page 4 of 13
Lazerpoint™ RF RX-92 Full-Function Receiver Installation Instructions
Section 4
Technical Data
Model TX-9 Transmitter
Frequency: Operates in the 902 – 928 MHz
ISM Band
Codes 1 million unique (20 bit) codes
Size 2 ¼” L x 5/8” W x 3/8” H
Mounting Double sided foam tape
Switch Connection 2 x 10” leads with ¼”
quick disconnect terminations
Built-in Piezo sounder Used for Low Battery status,
Battery Gauge™, and Stuck
Switch indicator.
Power 2 x AAA alkaline batteries
Battery life Minimum 500,000 operations
Range Over 500 ft (open area)
Temperature rating -40 to 185 F (-40 to +85 C)
Model RX-92 Receiver
Size 3 ½” L x 2” W x 1” H
Mounting 2 # 8 screws at 4” centers,
or Velcro (supplied)
Enclosure Clear plastic case
Operating voltage 12 / 24 Volts, AC / DC
Current Draw 23 mA nominal @ 24 VAC
63 mA maximum @ 24 VAC
+ 5 mA per RF module
Response time 30 – 200 ms
Operating Modes Via 4 dip-switches
Memory 40 transmitters
LED’s Indicate: relay status;
signal strength; learn mode;
erase mode & potentiometer
position
Outputs RX-92 – 2 x SPDT relays
Relay contact rating 3 amps @ 30 VDC
Time Delays 3 potentiometers:
Relay1 D.O.R. = 1 – 30 sec
Relay 2 D.O.O = 1 – 15 sec
Relay 2 D.O.R. = 1 – 30 sec
Electrical Life 1 x 105 minimum
Temperature rating -40 to 185 F (-40 to +85 C)
Certifications ·FCC Part 15 Compliant
·Canada RSS/CNR210:1078
1032 061A
·Meets: IEC60601-1-2:2007
Patent Pending
Accessories:
Plug-in daughterboard’s extend capability with other
frequencies. Refer to the following chart:
Daughterboard Operational Antenna
Model # Frequency Colour
RX-DBB 300 MHz Blue
RX-DBO 318 MHz Orange
RX-DBR 390 MHz Red
RX-DBW 433 MHz White
CM-RFCT: A 33” long cable-tool for high visibility of relay
status and signal strength
Section 5
Warranty
Camden Door Controls guarantees the Lazerpoint
RF (TX-9, RX-91,or RX-92 models) to be free from
manufacturing defects for 3 years from date of sale.
If during the first 3 years a Lazerpoint RF component fails to
perform correctly, it may be returned to our factory where it
will be repaired or replaced (at our discretion) without charge.
Except as stated herein, Camden extends no warranties
expressed or implied regarding function, performance or
service.
NOTE: Batteries are exempt from this warranty!
Questions?
Call us toll-free at 1-877-226-3369
