D
F
E
G
I
H
For traverse installation, two M10 threads are located on the base of the housing (Fig. H) to receive the traverse mounting bolts. (Fig. I, not included).
Secure the device via the integrated safety eyelets (Fig. J) and appropriate securing cables (not included). IMPORTANT: Overhead installation must
only be carried out by qualified personnel. When installing, please refer to the points under “CAUTION! IMPORTANT INFORMATION REGARDING FOG
MACHINES!” in this manual.
J
J
