TECHNICAL SPECIFICATIONS
ARTICLE
NUMBER:
CLROOTPAR4(WH) CLROOTPAR6(WH)
Product type: LED spotlight LED spotlight
Type: PAR spotlight PAR spotlight
Color spectrum: RGBW RGBWA-UV
Number of LEDs: 7 6
LED type: 4 W 12 W
LED PWM fre-
quency:
650 Hz, 1530 Hz, 2150 Hz, 4000 Hz
(adjustable)
650 Hz, 1530 Hz, 2150 Hz, 4000 Hz
(adjustable)
Beam angle (half
peak angle):
36.5° (19°) 36.0° (20.5°)
DMX input: 3-pin male 3-pin male
DMX output: 3-pin female 3-pin female
DMX modes: Without DMX delay channel:
2-channel, 4-channel 1, 4-channel
2, 5-channel, 6-channel, 9-channel
With DMX delay channel: 3-channel,
5-channel 1, 5-channel 2,
6-channel, 7-channel, 10-channel
Without DMX delay channel:
2-channel, 4-channel 1, 4-channel
2, 5-channel, 6-channel, 8-channel,
11-channel
With DMX delay channel: 3-channel,
5-channel 1, 5-channel 2,
6-channel, 7-channel, 9-channel,
12-channel
DMX functions: Dimmer, fine dimmer, strobe, red,
green, blue, white, color macros,
running light selection, DMX delay,
sound sensitivity
Dimmer, dimmer fine, strobe, red,
green, blue, white, amber, UV, color
macros, running light selection,
DMX delay, sound sensitivity
Controller: DMX512, IR remote control, W-DMX
(via optional iDMX stick)
DMX512, IR remote control, W-DMX
(via optional iDMX stick)
Stand-alone
functions:
Auto programs, sound programs,
static, color presets, user colors,
loop function
Auto programs, sound programs,
static, color presets, user colors,
loop function
Operating ele-
ments:
Mode, Enter, Up, Down Mode, Enter, Up, Down
Display elements: OLED display OLED display
Operating
voltage:
100–240 V AC / 50–60 Hz 100–240 V AC / 50–60 Hz
Power consump-
tion:
38 W 58 W
Illumination
intensity (@ 1 m):
7850 lx 10700 lx
Luminous flux: 1350 lm 1800 lm
