5. 0v
6. RS422 +ve output
7. RS422 –ve output
8. RS422 +ve input
9. RS422 –ve input
Ethernet Port RJ45 8/8 connector
Note the Ethernet Port uses an XPort adapter. Use the link below for configuring software.
http://www.lantronix.com/device-networking/embedded-device-servers/xport.html
A separate document is available to describe how to configure the XPort adapter. Note that
a serial to IP adapter will also be required to convert the joystick serial output to IP data.
1. TX+ Transmit Data +ve
2. TX- Transmit Data –ve
3. RX+ Receive Data +ve
4. Terminated
5. Terminated
6. RX- Receive Data –ve
7. Terminated
8. Terminated
Shield – 0v Ground
