Camera Corps Q3 - Q3 Interface Box; Fiber Option

Q3 – Operation Manual
Q3 Operation Manual V3.1
Page 16 4
th
April 2014
Q3 Interface Box
Head Cable Lemo 10w + Coax. 10m available
Inputs Audio Data (Camera Corps standard)
RS232, RS422, Ethernet IP
Genlock – BNC
Outputs HD-SDI x2 BNC
Composite Video BNC
RS232, RS422, Ethernet IP
Size 160mm x 103mm x 53mm
Weight 0.5 kg
Power Supply 9 – 36v DC Input. (XLR4 pin1 0v, pin4 +ve)
Consumption 12 watts (14.4watts with fiber card fitted)
Fiber Option
The fiber option includes a fiber box for the base end and a card which is fitted inside the QBall 3
interface box, together with cables to connect it to plugs on the PCB. It can be retro fitted by
customers.
Fiber type 2 x LC fiber connectors
Signals:-
Base to I/F Box Analogue Genlock Video
Audio Data
I/F Box to Base HD-SDI Digital Video
