HL540200, HL540210
www.campbellhausfeld.com
1 Lock washer - M6 ▲ ◆ 8
2 Head bolt - M6 x 50
▲
4
3 Cylinder head
▲
1
4 Head gasket
1
5 Valve plate
2
6 Metal gasket
1
7 Valve
2
8 Valve plate gasket
1
9 Cylinder
■
1
10 Cylinder bolt - M8 x 25
■
2
11 Cylinder gasket
1
12 Wrist pin
1
13 Compression ring
2
14 Oil ring
1
15 Wrist pin retainer
2
16 Piston
1
17 Connecting rod HL030300AV
1
18 Bolt - M6 x 20
◆
5
19 Nut - M6
❋
1
20 Eccentric — 1
21 Capacitor
●
1
22 Lock washer - M8 ■ ● 3
23 Nut - M8
●
1
24 Crankcase cover
◆
1
25 O-ring
1
26 Sight glass
1
27 O-ring
1
28 Drain plug - M5 x 10
1
29 O-ring
✖
1
30 Breather
✖
1
31 Crankcase cover gasket
1
32 Crankcase — 1
33 Washer - M5
❋
4
34 Shroud screw - M5 x 16
❋
4
35 Oil seal — 1
36 Bearing — 1
37 Rotor — 1
38 Bearing — 1
39 Stator (with thermal
protector) — 1
40 Rear end bell — 1
41 Fan
▼
1
42 Snap ring
▼
1
43 Plain washer - M5
❋
4
44 Lock washer - M5
❋
4
45 Motor bolt - M5 x 120
❋
4
46 Easy start valve HL036200AV 1
47 Washer
▲
4
REPLACEMENT PARTS KITS
▲
Cylinder head kit HL031200AV
■
Cylinder kit HL031500AV
●
Capacitor kit HL036400AV
◆
Crankcase cover kit HL031800AV
▼
Fan kit HL032200AV
Piston kit HL031600AV
Valve plate kit HL031400AV
Sight glass kit HL031900AV
Drain plug kit HL032000AV
Gasket kit HL031300AV
✖
Breather kit HL032100AV
— Not Available
❋
Standard hardware item - available at your local
hardware store
For Replacement Parts or Technical Assistance,
Call 1-800-543-6400
Please provide following information: Address any correspondence to:
- Model number Attn: Customer Service
- Serial number (if any) 100 Production Drive
- Part description and number as shown in parts list Harrison, OH 45030 U.S.A.
Replacement Parts List
