Quickstart Guide
MFD28/32 Gen2
Be excited, here is your CANchecked display.
Developed with enthusiasm and passion, your MFD28/32 Gen2 is a small device, that gives
you full access to your vehicle data. Please read this Quickstart Guide in its en rety. For more
detailed instruc ons, please refer to the manual.
Installa on instruc ons
You can  nd the vehicle-speci c
installa on instruc ons on our
homepage under "Help" or by
scanning the QR code.
Connec on
If you have the display with the vehicle-speci c connec on kit, please follow the installa on
instruc ons.
There are four connec on variants:
Variant 1 is OBD and gets igni on plus via pin 1 of the port (BMW and VAG).
Variant 2 is OBD and can be recognised by the separate red wire.
This must be connected to 12v switched (terminal15) in the fuse box
using the fuse adapter.
Variant 3 uses the vehicle-speci c connec on cable (e.g. BMW).
Variant 4 uses the accessory pack. Please follow the wiring diagram below.
Use a 2A fuse for the power supply (pin A5). The ground conects to A1.
Connect Can High to pin B2 and Can Low to pin B3. To connect other
accessories, see our manual.
What is included:
Display incl. vent adapter/
housing
Connec on cable with plugs or
vehicle-speci c connec on kit
Micro SD card (in display)
Micro SD to SD adapter
Op onal an -re ec ve  lm
Micro USB to USB A cable
installa on
manual
1
