Figure 2 b): flame divider
Figure 2 c): cap (underside)
The burner parts that can be dismantled for ordinary cleaning are the cap and flame divider. Do not use tools to dismantle the
parts. The removal of other burner parts is forbidden.
When cleaning the cut-off device, operate gently using a wet sponge.
The removal of parts of the appliance other than the burners (within the limits indicated above) or the pan restraint accessories is
forbidden.
holes for passage of the fastening pins
hole for passage of the cut-off device
recesses for coupling with fastening
pins
