AFTER COMPLETING EACH REASSEMBLY, ALWAYS CHECK THAT THE SEAL CONFORMS TO THE INSTALLATION
STANDARDS IN FORCE.
THE USE OF A NAKED FLAME IS STRICTLY FORBIDDEN.
TECHNICAL FEATURES
Installation class: 3
Fastening method:
M.S. SUPER silicone
Appliance category: *
Gas (group) and supply pressure: *
Total burner power (Q
n
): *
* see the plate on the first page, in accordance with the country of destination
The following tables show the technical data for each burner, in relation to the appliance categories.
For category: I3+
Burner
Gas
Pressure
(mbar)
Nominal
heat
capacity
(g/h)
Nominal
heat
capacity
(W)
Reduced
heat
capacity
- MINIMUM -
(W)
Nozzle
diameter
(1/100 mm)
Auxiliary
G30 (Butane)
G31 (Propane)
28 – 30
37
73
71
1000
400
52
Semi-fast
G30 (Butane)
G31 (Propane)
28 – 30
37
138
136
1900
450
69
Fast
G30 (Butane)
G31 (Propane)
28 – 30
37
218
214
3000
700
85
For category: I3B/P
Burner
Gas
Pressure
(mbar)
Nominal
heat
capacity
(g/h)
Nominal
heat
capacity
(W)
Reduced
heat
capacity
- MINIMUM -
(W)
Nozzle
diameter
(1/100 mm)
Auxiliary
G30/G31
(Butane/Propane)
30/30
73
1000
400
52
Semi-fast
G30/G31
(Butane/Propane)
30/30
138
1900
450
69
Fast
G30/G31
(Butane/Propane)
30/30
218
3000
700
85
