SPARE PARTS - SL1351-LC
The column "Pos." refers to the exploded drawing "TYPE SL1351-LC-O/LC-F" on page 57.
code
component
pos.
component
2000008 3
Hinge for glass lids
3000410 2
RH lid - SL1351
3000411 2
LH lid - SL1351
3000072 32
Tall rubber bushing for pan holders
3000073 1
Single-burner pan support AUX
3000074 1
Single-burner pan support SR
2000422 35
Silent-block spare parts kit
3000826 41
Mushroom hole cover for ø5.5 holes
4000026 29
2nd series lid stud bolt
4000170 2
Glass lid cable gland
4000224 7
Polyethylene intense black screw cap 2.5/12 mm
4000260 24
90-degree lowered black/chrome knob Ø 34
4000031 30
Universal nut for thermocouple
4000069 28
L600 thermocouple for fast-on magnet cock
4000025 20
Burner spreader for 2nd series AUX burner
4000021 21
Ø 55 perforated and enamelled cover 2nd series AUX burner
4000024 18
Burner spreader for 2nd series SR burner
4000019 19
Ø 75 perforated and enamelled cover 2nd series SR burner
3000826 5
Cap for blind holes Ø 5.5 PE black
4000318 22
Countersunk at head screw + M2.5 x 18 DIN EN ISO 7046 GV
4000223 8
Particle board screw PZD 4.5x20 ZN
4000253 26
Short piezo igniter 18 x 1.5 mm
4000232 27
Burner lighting glow plug L350
4000137 31
Clip for glow plug
4000229 32
TC M5 x 6 A2 ISO 7045 screw for hinge and silent-block fastening
3000520 25
Control panel sticker
2000289 45
Slide-out adjustable leg
VERSION O
code
component
pos.
component
4000432 43
Gas exible hose L1500 GOK STN/RSV ø8
VERSION F
code
component
pos.
component
---- 44
Gas connection tting may vary depending on the country of installation (EN 484: 2019 -
Annex A - Figures A.4
