EN 18
1
2
3
4
5
INSTALLATION OF THE APPLIANCE IN THE COLUMN
Insert the appliance into the column, placing it on
the opposite site of the hinges, and make sure 3-5
mm distance gap.
After ensuring the match between appliance door
and column door, then screw the appliance upper
part to the cabinet
Screw the appliance lower part.
Use a cross-screwdriver to loosen the connecting
pin underneath the right middle hinge, and adjust
to screw onto the right cabinet wall.
Fit the seal to the appliance, cut off the
excessive part if necessary. Fit the bottom
parts with plastic covers.
