Installation
Against the wall mounting method
11
10mm
A 10mm dimension should be reserved between the screws for fixing and hanging the whole
machine and the wall, so as to facilitate the installation of the whole machine. After hanging the
whole machine, a mounting screw will be driven into the expansion tube of the safety hole,
the screw should be completely tightened to prevent falling off.
When mounted against a
wall, the two sides can be
dangerous and need to be
guarded.
Safety holes
