Adjust seat height by loosening the seatpost collar.
Standing next to the bike, position the saddle so it’s the same height
as your hip.
Align the saddle with the frame and tighten the seatpost clamp
When riding, you should have a slight bend in your knee when the
pedal is at the bottom of its rotation.
Using the torque wrench, tighten the seat clamp to the specied
torque value.
Secure the front wheel between your legs and turn the
handlebar. If the handlebar and wheel move independently, the stem
bolts are not tight enough. Use the torque wrench and correct bit to
properly torque the bolts.
Attempt to rotate the handlebar forward and backward in the stem.
If it moves, the stem faceplate bolts are not tight enough.
Grab the front and rear of the seat and attempt to tilt it on the seat
post head. It should not move.
G.
H.
I.
J.
L.
M.
G
K
SET-UP STEP 2STEP 1 STEP 3 PRE-RIDE CHECK
L
I
