B
C
Select the correct bit for the stem bolts and install it
into the torque wrench.
Look for the torque specication markings on the front and back
of the stem, as well as the seatpost. If these markings are absent,
torque all stem, seatpost and seat collar bolts to 7 Nm.
Tighten the stem bolts in an ‘X’ pattern and ensure the gap is even
between the stem and faceplate at all four bolts.
Ensure the front reector points straight ahead,
perpendicular to the ground.
The rear reector must point straight back.
Gently pull the wheel reectors toward the rim to ensure they are
braced by the spokes.
A.
C.
D.
F.
D
E
SET-UP STEP 2STEP 1 STEP 3 PRE-RIDE CHECK
