Remove the disc brake pad spacer from the front caliper. Take care
not to pull the front brake lever while either the pad spacer or disc
brake rotor is not present in the caliper.
Carefully lift the bike from the box and gently place the fork ends on
the ground.
Remember: Do not turn your e-bike on during the assembly process.
The quick-release skewer is comprised of ve major parts: the skewer
itself; a washer; two conical springs; and the adjusting nut.
Unthread and remove the adjusting nut and the neighboring conical
spring from the skewer.
A.
C.
D.
A
B
D
E
SET-UP STEP 2STEP 1 STEP 3 PRE-RIDE CHECK
