Insert the skewer into the wheel axle on the opposite side of the disc
brake rotor. Push the skewer through the hub to the other side of the
wheel.
Place the conical spring back onto the skewer with the narrow end
pointing toward the wheel, then thread on the adjusting nut.
Gently lift the front end of the bike and roll the wheel back in-between
the fork legs, making sure the brake rotor goes in-between the brake
pads.
Tighten the skewer with a 6mm hex wrench while holding the
adjusting nut with your other hand. The wrench should leave an
imprint on your hand when properly tightened.
Lower the kickstand, then remove any additional packaging from the
bike.
F.
G.
H.
I.
J.
F
G
H
I
SET-UP STEP 2STEP 1 STEP 3 PRE-RIDE CHECK
