LCD Monitor
LCD Monitor:
LCD Monitor Brightness Levels:
Panel Coating:
Autofocus System
Number of AF Points:
AF Point Selection:
AF Activation:
AF Modes:
AF Sensitivity Range:
AF Microadjustment:
63
VIII. SPECIFICATIONS
New Clear View LCD monitor
• 3.0 inch (diagonal) TFT color; approx. 100% coverage
• Approx. 920,000-dot resolution
• Approx. 170° viewing angle
• Manually adjustable in 7 levels
• Auto LCD Brightness
■
Automatically adjusted by built-in light sensor (3 – brightness levels)
Anti-reflection and anti-smudge coating
• 9 – Visible AF Points
■
9 – AF points usable with all lenses f/5.6 and brighter
■
1 – “High-precision” cross-type sensor at center, lenses f/2.8 and brighter
• 6 – Assist-AF points
Not displayed in viewfinder. Assist-AF points function as needed when shooting in AI Servo AF.
■
4 – Horizontal-line sensitive points usable with f/5.6 lenses and faster
■
2 – High-precision, vertical-line sensitive points usable with lenses f/2.8 and faster
Light Source Detection Sensor provided to automatically compensate for the slight focus variations caused by
the spectral characteristics of different light sources. Especially effective when shooting in artificial light sources.
• Manual point selection
■
Using C.Fn III-3, AF point selection can be controlled with the Multi-controller,
Main Dial, or Quick Control Dial
• Automatic Selection
Pressing the shutter release halfway (SW-1), or pressing the “AF-ON” button
• One Shot AF
• AI Servo AF
• AI Focus AF
■
Camera automatically switches between One Shot AF and AI Servo AF
EV -0.5 ~ 18 (measured at 73°F and ISO 100)
Adjust all by same amount, or Adjust by Lens
