Canon imageClass LBP6230dw - Installing the Printer

2
Installing the Printer
Installation Requirements
Remove all the tape.
Do not remove the
packing material yet.
Rear CoverAuxiliary Tray
22.76 in. (578 mm)
6.34 in. (161 mm)
Top Cover
Multi-purpose
Tray
14.92 in.
(379 mm)
17.32 in.
(440 mm)
9.57 in.
(243 mm)
11.54 in.
(293 mm)
5.47 in.
(139 mm)
3.94 in.
(100 mm)
