9
When the printer cannot be found on the network
10
In the Finish window, select Restart my
computer now and click Restart.
11
When you restart the computer, the
software settings are enabled. The
software installation is now completed.
An iPFxxxx Support desktop icon
is created after installation. (iPFxxxx
represents the printer model.)
12
Next, follow steps 15-21 on page 7 to
install the electronic manuals.
If your printer cannot be found when connecting to
the network for the first time, setup an IP address
for the printer and then configure it on the printer.
When ink fills the system for the first time, after
printhead adjustment is finished, specify the IP
address on the printer's control panel.
• When ink fills the system for the first
time, do not operate the printer until
printhead adjustment is finished.
1
On the tab selection screen of the control
panel, press the
▲
and
▲
keys to select
(settings/adj. tab) and press OK.
678
Tot.Print Area(m2):
Maint.C Remain.: 80%
Printing
OK:Setting/Adj. Menu
2
Use the ▲ and ▼ keys to select Interface
Setup and press OK.
3
Use the ▲ and ▼ keys to select TCP/IP
and press OK.
4
Enter the IP address. Navigate through
the following menus using the ▲ and ▼
keys on the control panel.
1. Select IPv4 and press OK.
2. Select IPv4 Settings and press OK.
3. Select IP Address and press OK.
4. Enter the IP address.
MEM
How to enter IP addresses
1. Press the
▲
and
▲
keys to select a
field for inputting values.
2. Use the ▲ and ▼ keys to input values.
• Pressing ▲ increases the value by
one.
• Pressing ▼ decreases the value by
one.
• Holding down either the ▲ or ▼ keys
continually increases or decreases
the value.
3. Press OK once you have finished.
5
Press Menu.
6
Press OK on the registration confirmation
message that appears.
The IP address is set on the printer.
Next, restart installation of the printer
driver.
When entering the printer's IP address manually
In the IP Address Specification window,
select either IPv4 Address or IPv6
Address to enter the printer's IP address
and click Install.
The installation process begins.
• Ask your network administrator for the
IP address, as needed.
MEM
• IPv6 Address is displayed in Windows
7, Windows Vista, Windows Server
2008 R2, and Windows Server 2008.
9
After reviewing the installation results in
the Complete Installation window, click
Next.
88
Install the electronic manuals
7
In the Search Results window, select
Specify the IP address of available
printers in the network and click Next.
When the IP Address Specifications
window appears, follow the instructions of
"When entering the printer's IP address
manually" in step 8 to 12 on page 9 to
complete the installation of the software
and electronic manuals.
MEM
• If the following screen appears, click
Retry and select Specify the IP
address of available printers in
the network on the next screen that
appears.
To Next Page
