Package Contents
● Roll Unit
● Stacker
● Printer
Depending on your region, these might be included as standard or they might be available as optional accessories.
Refer to the included setup guides for details on the products included in the boxes.
The Manuals Supplied with This Printer
A. Printer
B. Paper for adjustment
C. Setup Guide (this manual)
D. Starter ink tanks (C, M, Y, MBK, BK)
E. Set of CD-ROMs
F. Set of printer documentation
G. Print head
H. Power cord
I. Holder stopper*
* The holder stopper is used when loading roll paper.
For details, refer to the Online Manual.
S. Rod holder (x 2)
T. Basket arm (x 2)
U. M4 Hex screw for basket arm (x 4)
V. Basket rod / Basket cloth
W. Basket locking support (x 2)
J. Stand leg L
K. Stand leg R
L. Stand stay
M. M4 hex screw (x 9)
N. M8 hex screw (x 4)
O. M8 Allen wrench
P. M4 Allen wrench
Q. Accessory pocket
R. 3-inch paper core attachment (x 2)
Only included with models where the stand is included as standard.
Furthermore, it may be packaged in a separate box depending on the
region where you purchased the printer.
● Basket
These items might not be included depending on your region.
● Stand
Note
• Some items are included with the printer but not described in this manual.
Keep these items in a safe place after setup because they are used in various printing applications.
• For instructions on the included items not described in this manual, refer to the Online Manual. ("How to Display the Online Manuals" on p.14)
• A cable to connect the printer to a computer is not provided with the printer.
Printed Manuals
Setup Guide (this manual)
Describes how to setup the printer.
Quick Guide
Contains information related to warnings for
using this product safely and information related
to replacing paper, ink tanks, and the print head.
Printer Stand Setup Guide*
Roll Unit Setup Guide*
Stacker Setup Guide*
Describes how to assemble the optional accessories.
Electronic Manuals
Online Manual
This manual describes advanced usage of the printer such
as paper saving tips, how to print a poster and banner with
the supplied software and print quality adjusting method, in
addition to the basic instructions for printing on roll paper or cut
sheet.
To view the electronic manuals, refer to "How to Display the
Online Manuals" (p.14).
The following manuals are included with this printer.
* Might not be included depending on your region and selected purchase options.
H
A
K
F E
L
T
T
Q
D
B
C
S
G
V
S
M, N, O, P, U R
J
I
W
