Canon LBP113w - Page 9

Quick Setup
3.
Take note of the SSID and network key.
• Check the label on the router.
User's Guide
• The setting operation is easier if the router is
provided with a WPS mark.
User's Guide
4.
Set the access point and network key
according to the screen below.
For more
information, refer
to the manual.
OK
1. Select <OK>.
2. Select <SSID Settings>.
3. Select <Select Access Point>.
4. Select the access point (SSID).
5. Enter a WEP key (network key), and Select
<Apply>.
6. Select <Yes>.
• The IP address will be automatically
configured in a few minutes.
• "Connected." is displayed.
5.
Install the driver and software.
P.10 "Installing the software"
Now you are finished with the
configuration of the initial settings.
To connect via USB
• The machine does not come with a USB cable.
Please have one ready, if necessary.
• Make sure that the USB cable you
use has the following mark.
• Do not connect the USB cable
before installing the driver. If you did, disconnect
the USB cable from the computer, close the
dialog box, and then perform the following
procedure from step 1.
1.
Install the driver and software.
P.10 "Installing the software"
• When the screen to connect the USB cable to
the machine is displayed, remove the tape that
covers the USB port.
Now you are finished with the
configuration of the initial settings.
For details
"Setting Up Using the Setup Guide" in the User's Guide
9
En
