CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-4
4) Turn the cable drive pulley [3] so that the three shafts [2] of the mirror positioning tool for the front
and the rear may be arranged as shown.
Figure 2-7 (rear)
Figure 2-8 (front)
[3][2]
[2]
[2]
[2]
