SWITCHABLE 4 : 3 (with crossover unit)16 : 9
Zoom Ratio
Built-in Extender
Range of Focal Length
Maximum Relative
Aperture
Angular Field of View
Minimum Object
Distance (M.O.D.)
Object Dimensions
at M.O.D.
Size
Weight (Approx)
Built-in Pattern Projector
NORMAL 4 : 3
1.0
2.0
1.0
2.0
1.0
1.2
2.4
55
9
500mm 18
1000mm 9
500mm 18
1000mm 7.4
407mm 9
500mm 18
1000mm
1:1.4 at 9~202mm
1:2.8 at 500mm
1:2.8 at 18~404mm
1:5.6 at 1000mm
1:1.4 at 9~202mm
1:2.8 at 500mm
1:2.8 at 18~404mm
1:5.6 at 1000mm
1:1.4 at 7.4~216mm
1:2.35 at 407mm
1:1.4 at 9~202mm
1:2.8 at 500mm
1:2.8 at 18~404mm
1:5.6 at 1000mm
52.1
40.3
at 9mm
1.01
0.76
at 500mm
27.5
20.8
at 18mm
0.50
0.38
at 1000mm
56.1
33.4
at 9mm
1.10
0.62
at 500mm
29.9
17.1
at 18mm
0.55
0.31
at 1000mm
52.1
40.3
at 7.4mm
1.01
0.76
at 407mm
43.6
33.0
at 9mm
0.83
0.62
at 500mm
22.6
17.1
at 18mm
0.41
0.31
at 1000mm
2.2m from front lens vertex
(with macro M.O.D:0.4m)
190
143cm at 9mm
3.4
2.6cm at 500mm
95
71cm at 18mm
1.7
1.3cm at 1000mm
207
117cm at 9mm
3.7
2.1cm at 500mm
103
58cm at 18mm
1.9
1.1cm at 1000mm
190
143cm at 7.4mm
3.4
2.6cm at 407mm
155
117cm at 9mm
2.8
2.1cm at 500mm
77
58cm at 18mm
1.4
1.1cm at 1000mm
244(W)
260(H)
549(L)mm
18kg (39.7lbs)
optionally available
Note ; SUPER 55 for 1/2 inch cameras is also available.
For details , please contact Canon office.
SPECIFICATIONS
ACCESS WINDOW FOR
EASY MAINTENANCE
•Easy adjustment of lens functions (Built-
in pattern projector, Iris gain) through a
large-size window.
EXCELLENT SERVO SYSTEM
•Faster and quieter servo system
•••
maximum speed zoom:0.8 sec
focus:0.8 sec
•Low power consumption
WIDE ANGLE OF 9MM
WITH REDUCED
DISTORTION
(ZOOM RATIO:55X)
LATERAL CHROMATIC
ABERRATION
•Full zoom range
•••••
maximum=6 microns
HIGH AND FLAT MTF
•Realization of high contrast in all areas of the
picture (center and corner)
PROTECTION FILTER (Optional)
COUNTERMEASURES AGAINST
"GHOSTING" AND "FLARES"
•New coatings and anti-reflection paint achieve
the elimination of "ghosting" and "flares"
COUNTERMEASURES AGAINST RADIO
FREQUENCY NOISE
(INTERFERENCE)
SERVO SYSTEM MATCHING ROBOTIC
REQUIREMENTS
•High resolution zoom and focus servo - 12 bit repeatability
10 BIT IRIS COMPATIBILITY
•High resolution iris control
4-POSITION TURRET
(built in extender, pattern projector,
master lens, crossover unit).
•Micro Computer Controlled
Turret.
*Built in Effect Filter available as
option e.g Cross, Sunny, etc.
VERSATILE
ZOOM/FOCUS
CONTROLLERS
(See figure on the next page )
•New ergonomic design.
•Countermeasures against dust,
rain, and radio interference.
CROSSOVER COMPATIBILITY (Optional)
•For use with 16:9/4:3 switchable cameras.
MACRO FUNCTION-M.O.D.=0.4M
To Next Page
