Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply 100-240 V AC (50/60 Hz)
Power consumption When printing: 59 W max. *1
In Sleep mode: 3.6 W max. *1
Standby (all ports connected): 3.6 W max.
When power is off: 0.3 W max. *2
*1 Wired LAN connection
*2 The printer uses a trace amount of power even when turned off. To stop all
power consumption, turn off the printer and unplug the power cord.
Operating environment Temperature: 59 to 86 °F (15 to 30 °C)
Humidity: 10 to 80 % RH (with no condensation)
Dimensions (W x D x H) Printer only:
Approx. 50.8 x 29.5 x 17.3 in. (1289 x 748 x 438 mm)
Printer and Stand SD-33 (when opening the basket):
Approx. 50.8 x 34.3 x 41.7 in. (1289 x 870 x 1059 mm)
Actual basket shipped with printer device may vary according to region.
Weight Printer only (without print head and ink tanks):
Approx. 97 lb (44 kg)
Printer and Stand SD-33 (without print head and ink tanks):
Approx. 117 lb (53 kg)
Space for installation (W x D x
H)
Printer only:
Approx. 66.5 x 53.1 x 29.1 in. (1689 x 1348 x 738 mm)
Printer and Stand SD-33 (when opening the basket):
Approx. 66.5 x 57.9 x 53.6 in. (1689 x 1470 x 1359 mm)
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi (horizontally) * x 1200 dpi (vertically)
* Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Print head PF-06
Number of nozzles MBK: 5120 nozzles, others: each 2560 nozzles
443
