Canon XF300 User Manual

8
Onscreen Markers and Zebra Patterns 81
Displaying Onscreen Markers 81
Displaying Zebra Patterns 82
Setting the Time Code 84
Selecting the Running Mode 84
Selecting Drop or Non-Drop Frame 85
Putting the Time Code Display on Hold 85
Setting the User Bit 87
b Synchronizing with an External Device 88
Connecting an External Device 88
Using a Reference Video Signal
(Genlock Synchronization) 89
Using a Time Code Signal 89
Time Code Signal Output 90
Recording Audio 91
Using the Built-in Microphone 91
Using an External Microphone or Line Input 92
Adjusting the Audio Level 94
Monitoring the Audio with Headphones 96
Using Metadata 97
Setting a User Memo 97
Colors Bars/Audio Reference Signal 98
Recording Color Bars 98
Recording an Audio Reference Signal 98
Video Scopes 99
Displaying a Video Scope 99
Configuring the Waveform Monitor 99
Configuring the Vectorscope 100
Configuring the Edge Monitor 100
Adding Shot Marks while Recording 102
Reviewing a Recording 103
Special Recording Modes 104
Interval Recording Mode 104
Frame Recording Mode 106
Slow & Fast Motion Mode 107
Pre-recording Mode 108
Optical Axis Shift 110
Using the Focal Length Guide 111
4. Customization 113
Assignable Buttons 113
Changing the Assigned Function 113
Using an Assignable Button 114
Custom Picture Settings 115
Selecting Custom Picture Files 115
Editing a Custom Picture File’s Settings 116
Renaming Custom Picture Files 116
Protecting Custom Picture Files 117
Transferring Custom Picture Files 117
Embedding Custom Picture Settings in a
Recording 118
Available Custom Picture Settings 119
Customizing Functions and Onscreen
Displays 126
Customizing Functions 126
Customizing Onscreen Displays 127
Saving and Loading Camera Settings 128
Saving Camera Settings to an SD Card 128
Loading Camera Settings from an SD Card 128
5. Playback 129
Playback 129
Clip Index Screen 129
Playing Back Clips 131
Onscreen Displays 131
Playback Controls 133
Adjusting the Volume 134
Adding Shot Marks during Playback 134
Clip Operations 135
Using the Clip Menu 136
Displaying Clip Information 136
Adding e Marks or Z Marks 137
Deleting e Marks or Z Marks 138
Copying Clips 138
Deleting Clips 140
Deleting the User Memo 140
Copying a Custom Picture File Embedded in a
Clip 141
Displaying an Index Screen of Shot Marks 141
Displaying a Frame Index Screen of a Single
Clip 142
Adding or Deleting Shot Marks from an Index
Screen 143
Changing a Clip’s Thumbnail 144
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
