Canvas BALA KVS148G User Manual

7
ASSEMBLY
Step 3
Requires: 1, 2, 3, 5, A, and B
Fasten the left side frame 5 to the base assembly-A 2 and the base assembly-B 3
by using bolts A. Fasten the
left side frame 5 to the seat assembly 1 by using
bolts B. Do not tighten bolts.
A B
A B
B
5
3
2
A
A
1
Step 4
Requires: 4, 5, 6, 7, A, and B
Fasten the back assembly 6 to the left side frame 5 by using bolts B.
Fasten the
support 7 to the right side frame 4 and the left side
frame
5 by using bolts A. Do not tighten bolts.
A
B
4
5
6
7
