Canvas CABANA User Manual

2 people
Model NO. 088-2075-2
4
PARTS LIST
5
ASSEMBLY PREPARATION
• Do not place the product underneath electrical lines.
• Keep children away during assembly.
• This product contains small parts which can be swallowed by
children.
• Keep fingers away from places where they can be pinched or
trapped.
CAUTION!
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE.
CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call ou
r
customer service toll-free helpline. Contact us for assistance;
we're here to help.
IMPORTANT: Please read and understand this manual before any assembly.
Before beginning assembly of product, make sure all parts are present. Compare
parts with packaging contents list. If any part is missing, or if you have any questions,
contact the service centre at 1-888-670-6684 (toll free).
Place all parts from the box in a cleared area and position them on the floor
in front
of you. Remove all packing materials and place them back into the box. Do not
dispose of the packing materials until assembly is complete. Read each step carefully
before beginning any assembly and make sure you understand each step.
Needed for assembly:
B
Upper bracket - 1
Lower bracket - 1
A
B
C
Base tube - 1
D
Upper base cover - 1
E
Lower base cover - 1
F
Pedal - 1
G
Turn plate - 1
H
Side base - 2
I
Middle base - 2
J
Crank - 1
K
Umbrella shade - 1
AA
M10x25 bolt - 4
BB
M10x20 bolt - 4
CC
Flat washer - 8
DD
M6x10 bolt - 1
EE
M6x10 flat bolt - 1
FF
M6 hex wrench - 1
GG
M10 hex wrench - 1
FOR EASY ASSEMBLY, DO NOT COMPLETELY TIGHTEN BOLTS
INTO THE FRAME UNTIL ALL BOLTS HAVE BEEN INSERTED FOR
THAT PHASE OF ASSEMBLY. ONLY AT THE FINAL STEP OF
ASSEMBLY, SECURELY TIGHTEN ALL BOLTS AND HARDWARE.

Canvas CABANA Specifications

General

Brand	Canvas
Model	CABANA
Category	Patio Furniture
Language	English
