Canvas MAYFIELD 068–7852–0 User Manual

PARTS LIST
Door stop - 1
F
G
H
I
J
K
L
M
N
Screw 5 x 50 mm - 2
Hex wrench - 1
Castor - 3
Crosshead nut - 4
Cam bolt (large) - 16
Cam (large) - 16
Bolt M6 x 60 mm - 4
Locking castor - 2
Wood dowel 7.8 x 30 mm - 22
Glue - 2
Rail track (left) - 2
Screw 3.5 x 12 mm - 24
A
B
C
D
E
Rail track (right) - 2
O
P
Q
R
S
Screw 4 x 30 mm - 3
Hinge - 4
Handle - 2
T
Bolt M4 x 22 mm - 6
U
Shelf pin - 4
V
Cam (small) - 4
W
Wood dowel 5.8 x 30 mm - 4
X
Handle - 2
Y
Screw 3.8 x 35 mm - 8
Z
Cam bolt (small) - 4
Screw 4 x 14 mm - 20
Screw 4 x 14 mm - 24
5
