6 MODEL NO. 068–7852–0
ASSEMBLY
•
•
•
•
HELPFUL HINTS
Read each section carefully before starting. It is very important that each step is performed in
the correct order. If these steps are not followed in sequence, assembly diculties will occur.
Make sure all parts are included. Most board parts are labelled or stamped on the raw edge.
Work in spacious area, preferably on a carpet, near the place the unit will be located.
Do not use power tools to assemble your furniture. Power tools may strip or damage the parts.
• Identify, sort and count the parts before beginning assembly.
• Compression dowels should be tapped in with a rubber mallet.
• Slides have a lip on the right side only.
• Back panels provide stability and support. Unit may collapse without the back panel installed.
• Clean the product with your choice of furniture polish and a soft cloth. DO NOT USE harsh
chemicals nor abrasive cleaners.
• Move your new furniture carefully. Two people are needed to lift and carry the unit to its new
location.
• Never push nor drag your furniture (especially on a carpet).
Needed for assembly:
Rubber mallet
Star-head
screwdriver
Flat-head
screwdriver
2 people
Important Note:
+/- on the cam should be positioned
as shown.
Do not overtighten the cam bolt.
1.
2.
3.
4.
5.
These illustrations show how the cam fastening system works.
160°~185°
To Next Page
