LISTE DES PCES
54
Support inférieur - 1
A
Support supérieur - 1
B
Tube du socle - 1
C
Unité pivotante de 360 - 1
D
Pédale - 1
E
Bras de support de repose-pied - 1
F
Boulon M10 x 25 mm - 4
G
Rondelle M10 - 8
H
Boulon M6 x 10 mm - 2
I
Connecteur de coin - 4
J
Panneau de verrouillage - 2
K
Panneau latéral - 2
L
Support circulaire pour tube - 2
M
Sac pour sable - 2
N
Couvercle de socle inférieur - 2
O
Couvercle de socle supérieur - 1
P
Manivelle - 1
Q
Parasol - 1
R
Clé hexagonale S8 - 1
S
Clé hexagonale S5 - 1
T
Clé hexagonale S4 - 2
U
Boulon M10 x 20 mm - 4
V
Boulon M6 x 66 mm - 2
W
Boulon M6 x 15 mm - 2
X
Clé - 1
Y
Nº de modèle : 088-0798-4
LISTE DES PIÈCES
Récepteur solaire - 1
Z
POUR FACILITER L’ASSEMBLAGE, NE SERREZ PAS COMPLÈTEMENT
LES BOULONS DANS LE CADRE AVANT D’AVOIR INSÉRÉ TOUS LES
BOULONS POUR CETTE ÉTAPE DE MONTAGE. SERREZ TOUS LES
BOULONS ET LES AUTRES ÉLÉMENTS DE FIXATION SEULEMENT À
LA FIN DE L’ASSEMBLAGE.
Nº de modèle : 088-0798-4
