STEP 3
1. Attach the corner chair
5 to the sofa seat frame 3 by
lining up the bolt holes on the corner chair
5 with the
corresponding bolt holes on sofa seat frame
3.
2. Using M6x52 combination bolt and washer
B, washer
D and nut E, lightly tighten the bolts using the hex key F
and wrench
G.
3. Tighten all bolts, then add M6 screw cover
H and screw
cover
J on the back frame as shown below.
5
F
D
H
X1
X1
X4
X1
E
B
G
J
X4
X4
X1
X1
H
F
F
B
B
D
5
5
5
3
3
3
E
E
J
G
G
D
NOTE:
Do not completely tighten.
