WHISTLER CONVERSATION SECTIONAL SET 9
STEP 2
1. Place the left arm
2 on a soft, flat surface. Attach the
loveseat seat frame
4 to the left arm 2 by lining up
the bolt holes on the loveseat seat frame
4 with the
corresponding bolt holes on the left arm
2. Using M6x32
combination bolt and washer
A, lightly tighten the bolts
using the hex key
F.
2. Tighten all bolts, then add M6 screw cover
H as shown
below.
4
X1
2
X1
F
X1
A
H
X4
X1
HH
FF
AA
AA
FF
B
D
D
B
A
4
4
A
F
F
2
2
H
NOTE:
Do not completely tighten.
