5
ASSEMBLY
(1) Remove the two pre-assembly
screws from the slide bracket.
(2) Attach the slide bracket to the
bottom of slide by using the two
pre-assembly screws.
Unscrew this black bracket
and discard. For shipping
only. Please recycle.
