Do not remove or cover the controls which are mounted on the tiller at the
factory, e.g. removing the clutch lever from the handlebar.
When the engine is running, do not pull the handle for forward speed and the
handle for rear speed at the same time! This will damage the transmission.
Always release one handle before the other is used.
"Beware of the rotating knives"
Working with the machine on a steep slope is
dangerous!
Only use the machine on areas where it can be
handled safely.
Assembly
1. Figure 1 shows the contents of the package:
a. Tiller with upper steer and cables.
b. Blades
c. Lower steer
d. Side guards
e. User manual and bolts
2. Mount lower steer using the accompanying bolts and nuts.
Figure 2.
3. Mount upper steer using the accompanying bolts and handwheels.
Figure 3.
4. Mount the side guards using the accompanying bolts and nuts.
Figure 4.
5. Mount the blades using the cotter bolts and pins.
It is important that the edge of the blade turns forward, as shown in figure 6, a.
Figures 5, 6.
WARNING: Follow the user manual guide to fill the engine with oil and fuel.
Clothing
When working with the tiller, wear close-fitting work clothes,
sturdy work gloves, hearing protection and boots with non-skid ¨
soles, and steel nose is compulsory.
Operation
Clean the area of all foreign items before use. Stone, glass, branches, etc. can damage the
tiller. Check that all bolts on the tiller are tightened.
