Tools required
1Power drill
2 Masonry bits
3 Steel drill bit 3.5 diameter
4 Pliers
5 Plain screwdriver
6Pozidrive screwdriver
7 22mm A/F spanner
8 Hacksaw
9 Small electrical screwdriver
10 Tape measure
NOTE: Where the garage door is the only means of access it is
recommended that the optional Exterior Release kit is fitted.
Contents of item 4 (bag)
QTY ITEM DESCRIPTION
3Track fixing screw No 8 × 1” S/tap C’/sunk
2 Chassis fixing screw No. 10
× 2” S/tap Pan HD
2 Cable tie
2 Gusset plate fixing No. 10
×
1
/2
” S/tap Pan HD
2Yellow wall plug for push button and No. 4
× 1”
S/tap C’/sunk screws
1 Cable clamp for latch cable
1 Split pin to retain door tension
1 Tilt bracket
top fixing screw No. 10 ×
3
/4"
”
S/tap Pan HD
1 Tilt bracket
bottom fixing screw No. 8 ×
3
/4
”
S/tap C’/sunk
2 Cable clamp fixing No. 6
×
1
/2
” S/tap Pan HD
1 Star lock washer for spindle
1 Cable fixture plus nut and washers
